    Anti - Corrosion Outdoor Disconnect Switch Good Conductivity 40.5kv High Voltage

    Ask Lasest Price
    Brand Name : Tianan Electric
    Model Number : GW4-40.5
    Price : Pending
    Payment Terms : L/C, T/T, D/A, D/P
    Supply Ability : 5000 sets per year
    Delivery Time : 30 work days
    • Product Details
    • Company Profile

    Anti - Corrosion Outdoor Disconnect Switch Good Conductivity 40.5kv High Voltage

    MonopoleType 40.5kv High Voltage Disconnect Power Isolator Switch in outdoor


    General

    GW4-40.5 series outdoor high voltage disconnector used for open of closing circuits under voltage but no-load condition in 12KV outdoor electrical system. It has fixed drawhook and self-locking device, effect operation with insulating hook-stick. Anti-pollution type can effectively solve flash due to pollution during the operation to satisfy the requirement of users in strong pollution area.


    Environmental Conditions

    • Suitable Altitude: 1000m
    • Suitable Temperature: -45℃ ~ +40℃
    • Relative Humidity: Daily mean ≤95%, monthly mean ≤90%
    • No conductivity dust.
    • No insulation object with devastating metal and corrosive gas.
    • No violent vibration and striking.
    • No explosive danger and fire.

    Main Features

    • High ability of anti-corrosion. All exposed steel parts are hot-dip galvanized; shaft pins are made of stainless steel; the surface of aluminium conductor is passivated; standard parts are hot-dip galvanized or made of stainless steel.
    • Reliable and stable drive. Adapters on driving part consist of clamping forks or joint ball shaft; shaft base is in fully-enclosed structure; Three-phase ganged operation is rezlized through touching connection with universial friction.
    • Good conductivity. Touch between outgoing pad contact piece and conductive rod is constructed by flexible connection; Outer-pressed stainless steel spring is used on contact piece; contacting part is silver-plated by finishing process.
    • Good property of operating mechanism.
