    Blokset Series Low Voltage equipment for high dependability muti-function system

    Ask Lasest Price
    Brand Name : Tianan Electric
    Model Number : Blokset
    Certification : VDE CCC ISO9001:2000 IEC62271:200
    Price : Pending
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 4000 PCS/YEAR
    Delivery Time : 40 work days
    • Product Details
    • Company Profile

    Blokset Series Low Voltage equipment for high dependability muti-function system

    Blokset Series Low Voltage Switchgear

    General
    >> A system for all your applications requiring a high level of dependability:
    ~~ Electrical distribution and motor control.
    ~~ A modular structure.
    ~~ For low-voltage switchboards, designed to meet local standards, practices and requirements.


    A multi-function range
    >> Type D: Distribution switchboards up to 6300 A
    >> Type DC: Power factor correction column
    >> Type Mf: Fixed-type motor-control centres up to 6300 A
    >> Type Mw: Withdrawable-type motor-control centres up to 6300 A
    >> Type Ms: Variable-speed drives and starters column
    >> Type C: Cubicles up to 630 A.


    A modular system
    >> Standardized components.
    >> Fast manufacturing.
    >> Easy modifications.


    Functional design
    1) Rationalized dimensions and layout inside the switchboard.
    2) Reduced footprint.
    3) Easy power and auxiliary connections .
    4) Easy installation upgrading at a controlled cost.
    5) An intelligent system, ready to integrate devices containing advanced protection and communication functions for electrical distribution and motor control.


    Compliance to standards
    >> Compliance with international standards: IEC 60439-1 / VDE 0660 part 500.
    >> DIN 41-488 / BS 5486 / EN 60 439-1.
    >> Seismic withstand: Uniform Building code, California Building code.


    Electrical Characteristics
    >> Rated insulation voltage: 1000 VAC
    >> Rated operational voltage: 690 VAC
    >> Rated impulse withstand voltage: 12 KV
    >> : IV
    >> Degree of pollution: 3
    >> Frequency: up to 400 Hz


    Main busbars rated current
    1. Main busbars Single busbars Double busbars
    2. Rated current,
    up to 4000 A up to 6300 A
    3. Rated peak withstand current 63, 105 187 kA 220 kA
    4. Rated short-time current 30, 50 85 kA r ms / 1 s 100 kA r ms / 1 s




    .
